Aguilar OBP - 3SK Onboard Bass Preamplifier
Brand: Aguilar
Model: OBP - 3SK
Description: The OBP-3 is Aguilar’s most flexible onboard preamp design, providing +/-18dB of cut and boost at 40Hz, +/- 16dB of cut and boost at either 400Hz or 800Hz and +/- 16dB of treble cut and boost at 6.5 kHz. The OBP-3 has multiple wiring options, and can be wired with either a push/pull pot OR mini-toggle for midrange frequency selection.
Brand: Aguilar
Model: OBP - 3SK
Description: The OBP-3 is Aguilar’s most flexible onboard preamp design, providing +/-18dB of cut and boost at 40Hz, +/- 16dB of cut and boost at either 400Hz or 800Hz and +/- 16dB of treble cut and boost at 6.5 kHz. The OBP-3 has multiple wiring options, and can be wired with either a push/pull pot OR mini-toggle for midrange frequency selection.
Brand: Aguilar
Model: OBP - 3SK
Description: The OBP-3 is Aguilar’s most flexible onboard preamp design, providing +/-18dB of cut and boost at 40Hz, +/- 16dB of cut and boost at either 400Hz or 800Hz and +/- 16dB of treble cut and boost at 6.5 kHz. The OBP-3 has multiple wiring options, and can be wired with either a push/pull pot OR mini-toggle for midrange frequency selection.
-
Brand: Aguilar
Model: OBP - 3SK
-
Bass Control: plus/minus 18 dB @ 40 Hz
-
Mid Control: plus/minus 16 dB @ 400Hz or 800 Hz. User-selectable frequency center
-
Treble Control: plus/minus 16 dB @ 6.5 KHz
-
Input Impedance: 1 meg ohm
Output Impedance: 100 ohm 9 or 18 volts operation
-
Distortion: .019 into 10k ohm load
-
Noise: -95 dBm unweighted
-
Battery Life: 324 Hours
-
Wire Lead Length: 6.50 inches
-
Dimensions: 0.98″W x 0.98″L x 0.59″D
-
Additional Information: Includes stacked Treble/Bass pot, Mid pot, and black mini-toggle switch for Midrange frequency selection. Aguilar does not include volume controls, battery terminal connectors, or output jacks with their onboard preamplifiers
